| Options: | SLR – steam lock release | |
| Equalizing plug or vent connection Internal strainer | ||
| Use: | Saturated and superheated steam. | |
| Available Models: | FLT14I-4,5 , 10 and 14 | |
| Sizes: | DN11/2” - DN2” ; DN40 – DN50 | |
| Connections: | Female screwed ISO7/1 Rp (BS21) | PMO - Max. operating pressure 14 bar |
| Flanged EN 1092-1 PN40 or ANSI | ||
| Installation: | Standard horizontal installation – | TMO - Max. operating temperature 198 ºC |
| From right to left FLT32 (R-L) | Max.differential pressure | |
| Upon request: | - horizontal installation with the flow from left to right (L-R) | |
| FLT14I-4,5 : 4,5 bar | ||
| - vertical installation with the flow from top to bottom (V) | FLT14I-10 : 10 bar | |
| FLT14I-14: 14 bar | ||
| 1 | Body | CF8M / 1.4408 |
| 2 | Cover | CF8M / 1.4408 |
| 3 * | Gasket | Stainless st./Graphite |
| 4 * | Seat | CF8 / 1.4308 |
| 5 * | Valve | AISI 420 / 1.4021 |
| 6 * | Lever | AISI 304 / 1.4301 |
| 7 * | Float | AISI 304 / 1.4301 |
| 8 * | Air vent | Stainless st. (Bimetallic) |
| 9 | Bolts | St.Steel A2-70 |
| Screwed | EN PN16 | ANSI 150 | ||||||||||
| Size DN | A | B | C | D | E | Weight Kg | F | b | Weight Kg | F | b | Weight Kg |
| 40 - 11/2" | 210 | 248 | 79 | 208 | 131 | 16.9 | 230 | 248 | 20.3 | 230 | 248 | 19.1 |
| 50 - 2" | 210 | 248 | 79 | 208 | 131 | 17.5 | 230 | 248 | 20.7 | 230 | 248 | 20.5 |
